Linear Motion Shaft Support

Name: Linear Motion Shaft Support
Brand: Vishnu enterprises
Price: 650 INR
Availability: InStock

Price 650 INR/ Piece

Get a Price/Quote

MOQ : 5 Pieces

Linear Motion Shaft Support Specification

Precision Rating
Standard machining tolerance, specific grades available on request

Retainer
Integrated mounting clamp

Thickness
Customizable, typically 20mm to 60mm

Inside Diameter
Same as bore size, customizable

Bearing Type
Not a bearing, it is a shaft support block

Material
Aluminum alloy or cast iron

Structure
Shaft Support Block

Seals Type
None (Direct shaft support)

Number Of Rows
Single

Bore Size
Customizable as per shaft diameter

Outside Diameter
Depends on shaft size (commonly 8mm to 40mm)

Limiting Speed
Depends on shaft and bearing-a support block itself does not limit speed

Load Capacity
Varies with model and material (typically up to several kN)

Operating Temperature Range
-20C to 80C

Application
For securing and supporting the ends of linear motion shafts

Mounting Type
Base/Side mounting through pre-drilled holes

Color
Silver (aluminum), dark grey (cast iron)

Fixing Method
Bolt clamp with recessed or through holes

Available Shaft Sizes
Commonly available for 8mm, 10mm, 12mm, 16mm, 20mm, 25mm, 30mm, 40mm shafts

Surface Finish
Anodized (for aluminum) or painted/ground (for cast iron)

Corrosion Resistance
High (for aluminum support); Moderate (for cast iron with surface treatment)

Linear Motion Shaft Support Trade Information

Minimum Order Quantity
5 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
2-5 Days

Main Domestic Market
All India

About Linear Motion Shaft Support

Discover a gilt-edged Linear Motion Shaft Support, available in limited stock from a distinguished supplier and trader in India. Crafted with transcendent precision, this support is indispensable for securing and sustaining the ends of shafts-from 8mm to a redoubtable 40mm. Each unit is engineered for value and durability, featuring base or side mounting via pre-drilled holes. The anodized aluminum variant offers high corrosion resistance in a gleaming silver finish, while the cast iron option is painted or ground in dark grey for moderate protection. Find unwavering performance with bolt clamp fixing, adaptable across demanding environments.

Versatile Use & Application

Linear Motion Shaft Supports are extensively used by manufacturers, machine builders, and automation engineers. Ideally suited for CNC machines, conveyors, and robotic systems, these supports efficiently secure and guide linear shafts. Application involves fastening the support using base or side mounting through pre-drilled holes, ensuring stable operation even under dynamic loads. Their robust construction and adaptable design make them reliable for varying industrial needs and shaft sizes.

Packaging, Export Markets & Supply Ability

Each Linear Motion Shaft Support is handed over in secure bulk packaging, ensuring safe delivery to industrial clients worldwide. Major export markets include Asia, Europe, and the Middle East, with a supply ability that accommodates bulk orders at the lowest price. Timely delivery and flexible logistics from reputable Indian suppliers and traders guarantee customers receive top value and uncompromised product integrity.

FAQ's of Linear Motion Shaft Support:

Q: How is the Linear Motion Shaft Support secured during installation?

A: The support is secured by bolting through recessed or through holes in the base or side, ensuring stable and precise shaft alignment.

Q: What are the available shaft sizes that can be accommodated?

A: The supports cater to shaft sizes ranging from 8mm to 40mm, covering most common industrial and automation applications.

Q: When should I choose aluminum over cast iron support?

A: Aluminum is preferred where high corrosion resistance and a lightweight solution are essential, while cast iron is suitable for heavier loads where moderate corrosion resistance suffices.

Q: Where is this product commonly used?

A: These supports are commonly found in CNC machines, conveyors, robotic assemblies, and various linear motion setups in industrial automation.

Q: What is the benefit of the anodized or painted surface finish?

A: Anodized finishes deliver enhanced corrosion resistance for aluminum supports, while painted or ground surfaces provide a protective layer for cast iron, extending product life and reliability.
